Van's RV-9
The Van’s RV-9 is a more docile touring-oriented member of the RV family, with a larger wing than the aerobatic RV-7 and RV-8. It is optimised for efficient cross-country flying rather than maximum manoeuvring loads. Its kit construction still gives owners wide freedom to personalise equipment.
.jpg){kind=link}
Did you know?
The RV-9 trades the RV-7 and RV-8's aerobatic edge for a larger wing built for efficient, docile cross-country touring.
Specifications
| Length | 6.3 m (21 ft) |
|---|---|
| Wingspan | 8.2 m (27 ft) |
| Height | 1.7 m (6 ft) |
| Maximum passengers | 1 |
| Persons on board | 2 |
| Crew | 2 |
| Maximum take-off weight | 0.8 t |
| Range | 850 NM (1,574 km) |
| Maximum speed | 170 kt (315 km/h) |
| Stall speed | 38 kt (70 km/h) |
| Service ceiling | 18,000 ft (5,486 m) |
| Optimum ceiling | 13,000 ft (3,962 m) |
| Rate of climb | 1,300 ft/min (6.6 m/s) |
| Take-off distance | 133 m (436 ft) |
| Landing distance | 100 m (328 ft) |
| Fuel capacity | 100 l |
| Engines | 1x Lycoming O-320 |
Curated by CatchFlights from manufacturer documents, ICAO Doc 8643 and reference works; values are left out where no source could confirm them. Sources are listed on our credits page.
